Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby flying scotsman123 » Thu Mar 27, 2014 11:40 pm

I still can't get over how amazing this project is, stunning work, sounds like the end is on the horizon?
Stone station in pre-grouping days, my layout.

User avatar
skyblue
Posts: 1738
Joined: Sat Aug 18, 2012 11:17 am

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby skyblue » Fri Mar 28, 2014 3:14 pm

I echo flying scotsman's comments - I still find it amazing to think that these coaches came out of a printer! I look forward to seeing more of your work.

User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Mon Mar 31, 2014 1:01 am

A small update on the GN / GNR Directors saloon...
Actually got round to doing some work on it, had all the parts laying round for months... so thought while I was waiting for the reprint I would get on and finish off this one. The body is prototype 2, and the chassis is prototype 3 which has revised parts for the coupling system and stronger supports for the over hangs.

So painting started last week or prep work did, and paint has been going on since Friday last week, to the point today where small detail parts are going on like the roof vents. The inside still needs to be painted, and some ideas on how to go about putting furniture in there when the time comes.


and a couple just on the layout...

HotBox53
Posts: 70
Joined: Sun Jan 06, 2013 8:52 pm
Location: Johannesburg

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby HotBox53 » Fri Apr 04, 2014 1:29 pm

Great work, and lots of credit due to you for persevering. If I may ask, which 3D printer are you using?
First class passengers remain seated!
Second class passengers get out and walk!
Third class passengers get out and push!

User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Fri Apr 04, 2014 11:55 pm

Thank you, and Shapeways.

fergy1
Posts: 11
Joined: Wed Mar 07, 2012 9:08 pm

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby fergy1 » Sat Apr 05, 2014 11:44 am

Excellent work, a real credit to you.

I'm interested in an N gauge version if ever you do sort out the problems! :)

User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Sat Apr 05, 2014 10:12 pm

Yes there will be an N version but not by me, will be done by someone else, no idea on time frame at the moment.

User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Fri May 02, 2014 2:33 pm

As of yesterday the Chesham Metropolitan Coaches are now available to the public from our Shapeways shop, there are a few things to read before ordering to ensure the quality of the print: https://docs.google.com/file/d/0B_s5cq6YuUSwbF82R3JaVDlQa1k/edit

The 2 coaches now available are the Brake 3rd (387), and the all 3rd (394).

I have made a small video on the coaches which you can have a look at, also will be writing up a PDF on how to finish them in the not to distant future probably towards the end of May.
https://www.youtube.com/watch?v=A-HPSoKE7xM

Also finished but not at this time released is the first GN Saloon. A few minor bits are still to be added.

User avatar
Bushey Troughs
Posts: 986
Joined: Sun Jan 07, 2007 3:25 pm
Location: MAIGH EO. Irelands Wild West.
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby Bushey Troughs » Fri May 02, 2014 7:06 pm

Excellent Matt, when Heljan bring out their Metropolitan Bo-Bo, I'm up for several.

I hope you're receiving adequate renumeration for all your time, and hard work.
COLIN.
“What experience and history teaches us is that people and governments have never learned anything from history, or acted on principles deduced from it”


User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Fri May 02, 2014 7:46 pm

Several? they only ran in sets of 3 lol.
Yes indeed the Heljan Bo-Bo is not far off, November / December this year... must say I am tempted but have to wait on the price to decide.
I am glad you like them, not sold any yet... even with Shapeways offering 15% off at the moment...
Just test printing the composite which was ordered yesterday.

User avatar
Bushey Troughs
Posts: 986
Joined: Sun Jan 07, 2007 3:25 pm
Location: MAIGH EO. Irelands Wild West.
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby Bushey Troughs » Fri May 02, 2014 9:43 pm

"Several, being more than two but fewer than many in number or kind:"

That would be about three for me then. :wink:
Class work Matt, wish I had the patience, I'm still up for three though Heljan Bo-Bo, and being solvent/deceased at the time of issue could be a big influence.
COLIN.
“What experience and history teaches us is that people and governments have never learned anything from history, or acted on principles deduced from it”


User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Sat May 03, 2014 11:33 am

haha alright, yea 3 I think was the norm, Bluebells set had an extra comp added before it was sent down to them.

Yes a lot of patients and a lot of help, was a team effort, original design is basically the same it's just been developed over the year, was a year and 2 months to get the first one finished and running...

User avatar
mattmay05
Posts: 1954
Joined: Wed Dec 12, 2007 4:16 pm
Location: Isle Of Wight
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby mattmay05 » Wed May 14, 2014 4:48 pm

Composite (412) Test print arrived a few days ago. I shall be having a chat to the co-designed this weekend at an appropriate location the London Transport museum.
This model has a revised chassis, in terms of size of the battery / electrical boxes, which are now bigger, and these updates have been put on the other chassis.


User avatar
tom92240
Posts: 323
Joined: Fri Jun 06, 2008 1:03 pm
Location: Tunbridge Wells West (75F)
Contact:

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby tom92240 » Mon May 26, 2014 7:04 am

mattmay05 wrote:Several? they only ran in sets of 3 lol.
Yes indeed the Heljan Bo-Bo is not far off, November / December this year... must say I am tempted but have to wait on the price to decide.
I am glad you like them, not sold any yet... even with Shapeways offering 15% off at the moment...
Just test printing the composite which was ordered yesterday.


Depends how pedantic you want to be :P In 3-car sets they were steam hauled ;)

noel
Posts: 435
Joined: Sun Dec 23, 2007 1:27 pm

Re: 3D Printing –Met Chesham Coaches, 4mm/OO, GN Saloon.

Postby noel » Thu May 29, 2014 5:11 am

+

Matt:

There is a fixed charge on each print, and if you put 2 bogies on the same print you will make
considerable savings, especially with FUD.

Noel
