The coegnant Branch is an add on board for either the Blue line Garden Railway or the fiddle yard in the garage. Its is based on a model of Coegnant colliery in the Llynfi valley South Wales. The first version will be based on the colliery as it was soon after nationalisation. Here are the first pics

Last edited by paulsrail on Tue Jul 07, 2009 8:28 pm, edited 1 time in total.
Paul
Re: Coegnant branch of the Blue line
nice looking models in the making there!!!
Re: Coegnant branch of the Blue line
These buildings look great Paul. Any chances of some pictures of the rest of the layout?
How did you build or where did you obtain the winding wheel? I really like the internal steam engine. Are you working from photographs or original plans?
Interesting and quality stuff.
How did you build or where did you obtain the winding wheel? I really like the internal steam engine. Are you working from photographs or original plans?
Interesting and quality stuff.
- hobby boy
- Posts: 430
- Joined: Sat Mar 14, 2009 8:22 am
- Location: Basingstoke, Hampshire, United Kingdom
- Contact:
Re: Coegnant branch of the Blue line
is that small windmill type thing used for pumping water
(in real life)
Hobby Boy


Hobby Boy
I have this engine like the picture
GWR 0-6-0 Pannier tank
Check out Andrew's layout Hookstoke Junction UPDATED! Should do more work as it's now the Easter Holidays
After the holdiays are over, my layout won't get updated much Age = 15

Check out Andrew's layout Hookstoke Junction UPDATED! Should do more work as it's now the Easter Holidays

Re: Coegnant branch of the Blue line
The small windmill thing is the partly constructed steam engine driving the winding drum. Only the drum will move and is built to the correct diameter to give the correct position for the openings in the wall for the Overwind and Underwind ropes. The diameter of the drum being a minimum 150 times the dia of the rope.
Paul
Re: Coegnant branch of the Blue line
Hi Grotland
I,ve done extensive research on the colliery mainly from photographs. The winding engine drum is made from mdf sides and a plasic bottle for the drum it,s self. This first model is set during modernisation in the 1950,s In fact the winding houses have been extended to allow for new electrical gear which has not been installed yet. I will not be installing the new fanhouse either as a number of railway line were removed to make way for it. More photos to follow
Paul
I,ve done extensive research on the colliery mainly from photographs. The winding engine drum is made from mdf sides and a plasic bottle for the drum it,s self. This first model is set during modernisation in the 1950,s In fact the winding houses have been extended to allow for new electrical gear which has not been installed yet. I will not be installing the new fanhouse either as a number of railway line were removed to make way for it. More photos to follow
Paul
Paul
Re: Coegnant branch of the Blue line

These photos show the sheave from the colliery and my model version

Paul
Re: Coegnant branch of the Blue line

Now you are just showing off....great skill and imagination shown here.
High towards the far post,Howard with a header,Hes done it!Steve Howard has scored for Leicester City,Bedlam here at the Walkers Stadium. the Leeds United players are flat out on the turf in utter despair. Leicester City are going to win again
Re: Coegnant branch of the Blue line
An interesting little project. Excellent start to the buildings
Dave
Dave
Re: Coegnant branch of the Blue line
I decided to put some detail inside the buildings which will be lit. The winding houses will have a revolving drum but the steam engine will be static. Two commpressors have been made for the compressor house, these were made of card and the tops of Carex soap dispensers
